DX 4000 ROTARY VANE COMPRESSOR

Oil-less rotary vane compressors with carbon vanes, built in suction filters, air cooled aftercooler (K model), pressure regulating valve, flanged to a TEFC motor

UNIT TYPE:
T 4.16 DV
T 4.25 DSK
T 4.40 DSK

MOTOR POWER:

Capacity	Max Pressure	Motor Power	Speed	Noise level	Weight w/motor
CFM	PSIG	HP	RPM	dBA	Lbs
7.1	15	0.6	1750	62	35
7.1	15	0.6	1750	62	35
7.1	15	0.6	1750	62	35
11.2	15	0.9	1750	64	52
11.2	15	0.9	1750	64	52
11.2	15	0.9	1750	64	52
17.7	15	1.8	1750	68	81
17.7	15	1.8	1750	68	81
17.7	15	1.8	1750	68	81
28.3	15	2.9	1750	70	101
28.3	15	2.9	1750	70	101
28.3	15	2.9	1750	70	101
